Overview
Venus Max – 78kW – 308kW Denso fuel system.
LP443EG3, LP443EG4, LP443EG5, LP443EG6, LP665EG1, LP665EG2, LP665EG3, LP665EG4, LP689EG1, LP689EG2, LP689EG3, LP689EG4.
The VENUS MAX engines produce power in the 78kW to 308kW range. The robust and versatile engine offers Denso high-pressure common rail fuel injection with ECU control. High flow oil filters, and cyclone air filter system ensure the engine is always in prime condition. The Venus Max range complies with Stage III emission regulations.
Switchable dual-frequency of 1500
Low maintenance – 20,000 hours between overhauls
Dependable – high strength cast iron block, easy cold starting down to minus 40ºC, at altitudes up to 4500m
Denso ECU-controlled common rail injection
Turbo-charged, air-to-air intercooler.
| Cooling System | Liquid |
| Minimum Full Load Speed | 1500 r/min |
| Maximum Full Load Speed | 1500 r/min |
| Number of Cylinders | 6 L |
| Bore | 105 mm |
| Stroke | 124 mm |
| Displacement | 6.5 litres |
| Injection | Denso Common Rail with ECU |
| Aspiration | Turbo & Air to Air Intercooler |
| Starting | Electric |
| Firing Order | 1-5-3-6-4-2 |
| Max Operating Temp | 52℃（122℉） |
| Weight | 713 kg |
| Length | 1632 mm |
| Width | 876 mm |
| Height | 1213 mm |
