LP625EG6 Generator
The six-cylinder MARS MAX LP625EG6 Generator series produces power in the 460kW to 800kW range at either 1500. These series-turbocharged engines feature a compact single air cleaner making overall height only 1659mm. Liebherr common rail fuel injection system and ECU delivers class-leading power.
Mars Max MAX LP625EG6 Generator Overview
Fixed Speeds – 1500 r/min
Maximum Power – 1500 r/min—754kW
Injection – ECU
The six-cylinder Mars Max MAX LP625EG6 Generator series produces power in the 460kW to 800kW range at either 1500 or 1800rpm. These series-turbocharged engines feature a compact single air cleaner making overall height only 1659mm. Liebherr’s common rail fuel injection system and ECU delivers class-leading power.
Series-turbocharging allows high altitude operation at up to 5000m, with no more than a 30% derate when above 4500m
Can operate at temperatures down to minus 35ºC
Takes one-step loads of up to 500kW
Fuel and emissions efficient electronic high voltage common rail injection
500 Hour service intervals (depending on working conditions)
Low single-air cleaner to help reduce package size.
Lister Petter MARS MAX LP625EG6 Generator Specs
| Cooling System | Liquid |
| Minimum Full Load Speed | 1500 r/min |
| Maximum Full Load Speed | 1500 r/min |
| Number of Cylinders | 6 L |
| Bore | 170 mm |
| Stroke | 185 mm |
| Displacement | 25.18 litres |
| Injection | Denso Common Rail with ECU |
| Aspiration | Turbo & Air to Air Intercooler |
| Starting | Electric |
| Firing Order | 1-5-3-6-4-2 |
| Max Operating Temp | 52℃（122℉） |
| Weight | 2900 kg |
| Length | 2635 mm |
| Width | 1608 mm |
| Height | 1936 mm |
