Overview
Mars Max
LP625EG1, LP625EG2, LP625EG3, LP625EG4, LP625EG5, LP625EG6, LP625EG7, LP625EG8, LP625EG9, LP625EG10, LP625SG1, LP625SG2, LP625SG3, LP625SG4
The six-cylinder MARS MAX series produces power in the 460kW to 800kW range at either 1500. These series-turbocharged engines feature a compact single air cleaner making overall height only 1659mm. Liebherr’s common rail fuel injection system and ECU delivers class-leading power.
Series-turbocharging allows high altitude operation at up to 5000m, with no more than a 30% derate when above 4500m
Can operate at temperatures down to minus 35ºC
Takes one-step loads of up to 500kW
Fuel and emissions efficient electronic high voltage common rail injection
500 Hour service intervals (depending on working conditions)
Low single-air cleaner to help reduce package size.
| Cooling System | Liquid |
| Minimum Full Load Speed | 1500 r/min |
| Maximum Full Load Speed | 1500 r/min |
| Number of Cylinders | 6 L |
| Bore | 170 mm |
| Stroke | 185 mm |
| Displacement | 25.18 litres |
| Injection | Liebherr Common Rail with ECU |
| Aspiration | Turbo & Air to Air Intercooler |
| Starting | Electric |
| Firing Order | 1-5-3-6-4-2 |
| Max Operating Temp | 52℃（122℉） |
| Weight | 2900 kg |
| Length | 2635 mm |
| Width | 1608 mm |
| Height | 1936 mm |
