T1 Air Cooled Irrigation Pump Set

T1 Air Cooled Irrigation Pump Set OVERVIEW

T1 Air Cooled Irrigation Pump Set Engine outputs used for the design of the pump sets are continuous ISO 3046 ratings under NTP conditions. Considering standard operating site conditions, the pump sets are designed to ensure optimum performance. The engine selection is made with at least a 20% differential between the power absorbed by the pump and the engine output. This is to take into account site atmospheric conditions and poor fuel quality. In the event of high altitudes, please refer to LPL engineering to check engine compatibility. The engine outputs after the above de-rating must be checked against the absorbed power by the pump.

Water flow 28 – 550 m3/hr

10638 T Series Irrigation Pump Sets TDS (002)

T1 Air Cooled Irrigation Pump Set STANDARD FEATURES

▪ Lister Petter T series air cooled, direct injection, naturally
aspirated (1, 2 and 3 cylinders)
▪ Hand start
▪ Starting handle
▪ Continuous operation for up to 24 hours a day
▪ Stationary or mobile configuration
▪ Steel formed baseplate in black powder coating finish with
2 Positioning feet under the base
▪ 12.1 Litres polypropylene fuel tank
▪ Heavy-duty, single-stage, centrifugal, end suction pump with cast
iron casing and impeller
▪ Suction and delivery flanges conforming with DN2533/PN16 –
ISO7005-2/PN16

OPTIONAL ITEMS
▪ 12V Electric start, control panel, battery, and leads

▪ Off-road trailer with 2 wheeled axles, tow bar, and positioning
stands, towing speed limited to 25 km/hr maximum

▪Larger fuel Tank
